ZLP500 Temporary Cradle

ZLP500 Temporary Cradle – Professional Suspended Access Platform for High-Altitude Work

Hebei Xinjiuyi Construction Technology Co., Ltd. brings you the ZLP500 Temporary Cradle, a professionally built suspended get to stage planned particularly for little to medium-sized high-altitude operations. With a evaluated stack capacity of 500 kg and fueled by a double 1.1 kW × 2 engine framework, this gear serves as your portable airborne workstation for exterior work.

Our standard stage measures 5000 mm in length, advertising plentiful workspace for your team. The framework highlights a lifting speed of 9-11 m/min, empowering effective vertical development over numerous building floors. Suspended from the building beat by means of steel wire ropes, it involves zero ground space whereas adjusting to for all intents and purposes any working height.

You'll appreciate the adaptability this stage brings to ventures like multi-story private outside portray, little shade divider establishment, window cleaning, and outside separator development. The secluded plan permits for fast get together without complex setup strategies, getting your group working quicker and more safely.

Material Construction & Surface Treatment Options

Steel or Aluminum Platform Choices

Your ZLP500 Temporary Cradle comes with two fabric choices to coordinate your venture prerequisites and budget.

Steel Stage (400 kg): Built for toughness and quality, perfect for customary development work. The steel development gives fabulous solidness in different working conditions.

Aluminum Stage (290 kg): Weighing 110 kg less than the steel adaptation, this alternative decreases generally framework weight. The lighter plan makes transportation and repositioning more sensible for your crew.

Professional Surface Treatment

We apply hot-dip galvanizing as the standard surface treatment, giving solid erosion resistance for open air applications. For upgraded aesthetics and extra security, electrostatic shower coating is accessible as an overhaul option.

The devoted suspension instrument weighs 250 kg, with a counterweight framework of 750 kg guaranteeing steady operation. This adjusted plan keeps up stage soundness indeed amid moving operations.

Technical Specifications

Application Scenarios for Versatile High-Altitude Work

Building Facade Construction & Maintenance

Your team can efficiently handle exterior wall painting on multi-story residential buildings. The platform provides a stable work surface that moves smoothly alongside the building facade.

Small curtain wall installation projects benefit from the precise positioning capability. You can shift the platform horizontally and adjust height with stepless lifting control, placing workers exactly where they need to be.

Cleaning & Insulation Projects

Window cleaning operations become safer and more productive with this suspended platform. The 690 mm width provides comfortable working space while maintaining maneuverability.

Exterior wall insulation construction requires consistent access to vertical surfaces. Our ZLP500 Temporary Cradle delivers that access without the ground footprint and assembly time of traditional scaffolding.

Flexible Positioning for Complex Facades

The wire rope suspension system adapts to irregular building shapes and heights. You can reposition the platform around architectural features that would complicate fixed scaffolding installation.

Ground-level space remains clear for material delivery and other construction activities. This addresses one of the most common site logistics challenges in urban construction environments.

Customization Services for Your Specific Needs

Tailored Dimensions & Configurations

While our standard platform length is 5000 mm, we understand that your project might require different dimensions. Xinjiuyi offers customization services for platform length, working height requirements, and configuration adjustments.

You can specify the color scheme to match your company branding or project requirements. Surface treatment options can also be selected based on your working environment conditions.

Modular Design for Easy Transport

The equipment features standardized components that disassemble quickly for transport between job sites. Your crew can load, move, and reassemble the system efficiently.

Modular assembly means you don't need specialized tools or lengthy setup procedures. The platform is ready for operation shortly after arrival on site, maximizing productive working hours.

Safety Features & Operational Reliability

Integrated Safety Lock System

The LSA30 / LSA20 safety lock models provide automatic protection in emergency situations. These mechanisms engage immediately if descent speed exceeds safe parameters, securing the platform in position.

Dual motor configuration (1.1 kW × 2) offers redundancy in the power system. If one motor experiences issues, the platform can still operate with reduced capacity for safe descent.

Stable Suspension System

The 250 kg suspension mechanism is engineered to distribute loads evenly across the wire rope system. Combined with the 750 kg counterweight, this creates a balanced system that minimizes platform sway.

The LTD50 hoist model is specifically designed for suspended platform applications. It provides consistent lifting performance and reliable braking function throughout your work shifts.

Stepless Speed Control

Precise positioning is essential for facade work. The stepless lifting control allows your operators to adjust platform height smoothly, stopping at exact working points without jerky movements.

This fine control capability improves work quality while reducing operator fatigue during long shifts at elevation.

Frequently Asked Questions

Q1: What's the difference between the steel and aluminum platforms?

A1: The aluminum platform weighs 290 kg compared to 400 kg for steel, making it easier to transport and reposition. Steel offers maximum durability for heavy-use environments, while aluminum provides excellent corrosion resistance in coastal or humid conditions.

Q2: How quickly can the platform be assembled on site?

A2: Thanks to the modular design, an experienced crew can typically assemble the temporary cradle within 2-3 hours. No complex setup procedures are required, and standard tools are sufficient for assembly.

Q3: Can I customize the platform length for specific project requirements?

A3: Yes, absolutely. While our standard length is 5000 mm, we manufacture custom lengths based on your project specifications. Contact us with your dimensional requirements for a customized solution.

Q4: What maintenance is required for the suspension mechanism?

A4: Regular inspection of wire ropes, safety locks, and motor function is recommended according to your local safety regulations. The hot-dip galvanized surface treatment significantly reduces maintenance needs compared to untreated steel.

Q5: Is the platform suitable for coastal construction projects?

A5: Yes, particularly when specified with hot-dip galvanizing or the aluminum platform option. These treatments provide excellent corrosion resistance against saline environments common in coastal areas.

Q6: What's the maximum working height for this system?

A6: The product can operate at virtually any building height, as it's suspended from the roof structure. The practical limit depends on your building height and wire rope length specification.

Packaging & Delivery

Our packaging process ensures your equipment arrives ready for operation. Major components are secured in wooden crates with protective padding.

The suspension mechanism and counterweights are packaged separately for balanced load distribution during transport. Platform sections are bundled with protective corner guards to prevent surface damage.

All electrical components and safety locks are individually wrapped and clearly labeled. You'll receive complete documentation including assembly instructions and technical specifications with every shipment.

​​​​​​​
